Cryogenic tanks

We are reputed for manufacturing and supplying high quality cryogenic storage tanks. Our tanks are fabricated using the high quality materials and designs. The cryogenic tanks are used in industries such as metal processing, pharmaceuticals, chemical, aerospace, fisheries, healthcare, glassware, etc. We have been exporting such machinery all over the world to various prestigious companies. Our products stand out in the market because of their quality and unbeatable prices. We have got an experienced team of engineers who are responsible for designing and fabricating the storage tanks compliance with international standards. Components used in manufacturing of the tanks are bought only from the approved vendors.

Our cryogenic storage tanks come in various capacities and customers can order the one that meets their requirements. Being a quality conscious company, we ensure that all manufacturing processes comply with our quality control benchmarks. We have sold over 450 liquid storage tanks all over the world including Saudi Arabia, Qatar, Yemen, UAE, Algeria, Sudan, South Africa, Bolivia, Peru, Iraq, Iran, Afghanistan, etc. We have been given prestigious certifications like ISO 9001:2008 and CE.

Functioning of cryogenic storage tanks :
Structure

Cryogenic Vessel is essentially a double walled cylindrical tank, annular space between inner and outer vessel is filled with insulating material and evacuated to a high vacuum to achieve minimum evaporation losses. The cold converter is fitted with pressure building arrangement with automatic pressure build - up regulator.

Operation

Design of cryogenic equipment like vessels is compact, sturdy and easy to operate. Top end liquid filling reduces the pressure inside the tank and pressure increases in bottom filling. Pressurizing system enables operator to increase the pressure during liquid unloading to tanks or gas line vaporizers. By regulating the opening of both top and bottom filling valves, there is no significant change of pressure during liquid delivery. This results in constant liquid supply to vaporizer.

Capability

Storage at temperature up to (-196°C) ranging from 200 liters to 1,50,000 liters with option of low and high pressure Cold converters are used to allow the supply pressure pipe line networks after gasification in atmospheric heat exchangers, storage tanks supply networks or tanks of smaller capacity for low liquid temperature directly.

Salient features :
  • Simple tube structure
  • No need to replace the insulation material regularly
  • Excellent insulation and low static evaporation
  • Tank inter layer passes strict leakage test by helium gas spectrometer with a leak rate of less than 1 x 10 ?¹º pa-l/s
  • Convenient system operation and small area requirement
  • The tanks can supply cryogenic liquid from the bottom by connecting it to an outer vaporizer and cryogenic pump. We can supply the whole system along with the valve system and piping based on the customer requirement
  • Low area requirement, safety
  • Simple operating convenience
  • Vacuum powder insulation cryogenic tanks are used to supply liquefied oxygen, nitrogen, argon and other liquefied gases.
Applications of liquid storage tanks :
  • Metal processing, e.g. welding
  • Medical technology
  • Electronics
  • Water treatment
  • Energy (LNG, LH2)
  • Food industry
  • Environmental technology
